Refco Air Conditioning Refrigeration Vacuum Pump RL-8
Refco Vacuum Pump RL-8
Ideal for Air Conditioning and Refrigeration
The one with the maximum power and integrated ball valve makes it the high performance vacuum pump in the REFCO range. High quality components and sophisticated technology maintain the high performance of the two-stage rotary vane pump even at maximum load, so that the desired deep vacuum is reached faster.
Send in your used pump: we will overhaul it at a flat rate! Thus your vacuum pump purchase becomes a long-term investment in a quality tool!
- Low weight and highest quality thanks to the use of high-quality materials
- Gas ballast valve
- Internal oil circulation for optimum lubrication
- Easy reading of the optimum oil level (sight glass middle)
- Large oil filler neck for easy and clean filling of oil
- Special filter reduces oil mist at the blow-out nozzle
- Integrated ball valve for shut-off
- Stable and ergonomic handle
- Integrated on/off switch, protected against damage and accidental operation
- Refco part number: 4507348
Specification
| Flow Rate | 150 l/min |
| End Vacuum | 15 micron |
| Number of Stages | 2 |
| Voltage | 220 - 240 VAC |
| Frequency | 50 / 60 Hz |
| Rotational Speed | 2,800 rpm |
| Protection Class | I |
| Oil Tank Volume | 500 ml |
| Gas Connection | 1/4" SAE / 3/8" SAE |
| Packaging | Cardboard box |
| Material | Steel | Polypropylene |
| Colour | Yellow (RAL 1023) | Green (RAL 6026) |
| Standards | EN 60335-1 |
| EN 60034-1 | |
| EN 1012-2 | |
| EN ISO 12100 | |
| RoHS Conformity | Yes |
